Akupanel wooden slat accent wall manufacturer

Wooden slat panel is made of MDF Panel manufacturer + 100% polyester fiber panel. It can quickly transform any modern space, enhancing the visual and auditory aspects of the environment.

Product parameters

Acupanel wood panel Product Overview

The Acupanel wood panels are made from veneered lamellas on a bottom of a specially developed acoustic felt created from recycled material. The handcrafted panels are not only designed to fit in with the latest trends but are also easy to install on your wall or ceiling. They help to create an environment that is not only quiet but beautifully contemporary, soothing and relaxing.

Akupanel slat woodupp wall panel wholesale

Wooden slat panel is made of MDF Panel + 100% polyester fiber panel. It can quickly transform any modern space, enhancing the visual and auditory aspects of the environment. The soundproof wood Acupanel wood panels at the bottom are hand-crafted from the highest quality materials and are a specially developed acoustic felt made from recycled materials with sustainably recycled properties that reduce noise levels and are an effective solution to sound absorption while reducing noise reverberation time in the home.

Akupanel slat woodupp wall panel wholesale

Structure

Front Finish: Veneer or Melamine

Basic Material: MDF

Bottom: PET polyester Acupanel wood panels

Akupanel slat woodupp wall panel wholesale

It is a good acoustic and decorative material with characteristics of environmental

friendly, heat insulation, mildew proof, easy cutting, easy removal and simple installation etc. There are varieties of patterns

and colors and can be used to meet different styles and requirements.



Acupanel Application

Wooden slat panel can be widely used on walls and ceilings, in the living room, corridor,

kitchen, children's room, bedroom or office. They are also suitable for public communities, shops and restaurants, etc.

Akupanel slat woodupp wall panel wholesale

Product Specification

Model

Wooden Slat Wall Panel

Pattern

MDF 27mm, Edge to edge 13mm / customized

Standard Size

2400*600*21mm / customized

MDF Thickness

12mm/15mm/18mm

Polyester Thickness

9mm/12mm

Finish

Melamine / Veneer / Painting

Material

MDF + Polyester fiber

Bottom

PET polyester panel

Installation

Glue, wood frame, gun nail

Test

Eco protection, Sound absorption, Fire-retardant

Function

Sound absorption / Interior decoration

Application

Qualified for Home/ Musical instrument/ Recording/ Catering/ Commercial/ Office

Noise Reduction Coefficient

0.85~0.94,SGS Test for polyester panel

Akupanel slat woodupp wall panel wholesale



Product Features

Front Finish

The finish of the product is the surface with veneer or melamine. The veneer has small cracks, cams and beautiful flaws, which help create a natural and rustic look.

Akupanel slat woodupp wall panel wholesale

Akupanel slat woodupp wall panel wholesale

Akupanel slat woodupp wall panel wholesale

Basic Material (MDF)

Akupanel slat woodupp wall panel wholesale

Bottom: PET polyester Acupanel wood panels

Polyester fiber panel is made of 100% polyester fiber. It is a good acoustic and decorative material with characteristics of environmental friendly, heat insulation, mildew proof, easy cutting, easy removal and simple installation etc. There are varieties of patterns and colors and can be used to meet different styles and requirements.

Akupanel slat woodupp wall panel wholesale

Features:

With excellent sound absorbing performance. The NRC can

be 0.85 to 0.94.

Easy to cut by knife and easy to install by glue or nail

Good physical stability, will not inflate or shrink due to the

change of temperature

Soft and natural texture. It will not get broken under huge

impact of high elasticity.

Easy dust removal and easy maintenance by vacuum cleaner

or feather duste

Advantages

1.  Fit any design theme, from natural and earthy to stylish and modern

2. 2.  The panel is durable and easy to install

3. 3.  Soundproof boards are handmade from the highest quality materials

4. 4. The bottom is a specially developed acoustic felt made from recycled materials with sustainable recycling properties

5. 5. Helps create an environment, changing any space and enhancing the visual and auditory aspects of the environment

6. 6.  Reducing noise levels is an effective solution to sound absorption

Color chart



Akupanel slat woodupp wall panel wholesale

Product Features

The ultimate out of the box handcrafted acoustic slat wood wall paneling solution.

Enhance your space with our acoustic slat paneling for walls and ceilings. The Acupanel wood panels are made from veneered lamellas on a bottom of a specially developed acoustic felt created from recycled material. The handcrafted Acupanel wood panels are not only designed to fit in with the latest trends but are also easy to install on your wall or ceiling.They help to create an environment that is not only quiet but beautifully contemporary, soothing, and relaxing.

Akupanel slat woodupp wall panel wholesale

Akupanel slat woodupp wall panel wholesale





Scope of application

Akupanel – installation guide

In the downloadable PDF you will find detailed step-by-step instructions for installing the acoustic Acupanel wood panels.

Or you can follow the individual points below.

Steps 5 and 6, cutting the panels to size, need only be carried out if necessary. If the measurements fit for you, you will be finished after step 4 and can look forward to your result.

Akupanel slat woodupp wall panel wholesale

Materials needed for assembly:

· A saw - either a circular saw or a normal saw (foxtail)

· A screwdriver

· Screws for the Akupanels and the underlying battens

· » Black screws approximately 35 mm. for mounting the Akupanels

· » You will potentially need small screws (approximately 15 mm.) for fixing the

· lamellas on the filt when after cutting the Acupanel wood panels in length

· » Screws and plugs for mounting the battens on the wall

· Battens (we recommend 45 mm. in thickness)

· Mineralwool (45 mm. i thickness)

· A scale

· Pencil

Akupanel slat woodupp wall panel wholesale

Step 1: preparing the wall

· remove coarse impurities

· remove screws, nails etc.


Akupanel slat woodupp wall panel wholesale

Step 2: Mounting the underlying battens



Airst fix the battens to the wall to screw the screws through the felt of the acoustic Acupanel wood panels into the battens (plugs and screws may be required)

We recommend a distance of 40 cm between the slats



then insert the mineral wool between the laths on the wall (sound insulation class A)



alternatively, the acoustic Acupanel wood panels can also be mounted directly on the wall with screws or



glue (sound insulation class D)

Note: If the acoustic Acupanel wood panels are glued directly to the wall, you may damage the wall and/or the panels if the panels are detached.

Akupanel slat woodupp wall panel wholesale

Step 3: Insert mineral wool between the battens

· Insert a 45 mm thick mineral wool (or similar to the thickness of wooden slats) between the slats

· This can be cut with a knife and is then clamped between the slats


Akupanel slat woodupp wall panel wholesale

Step 4: Mounting the akupanels

· use black screws (35 mm) to screw through the black felt into the batten

· recommendation: 15 screws per acupanel


Akupanel slat woodupp wall panel wholesale

· The Acupanel wood panels have one side with felt and one with lamella

· When assembling in continuation to each other, please note that the felt side of the one panel is seamless with the slat side of the following panel

· this creates a joint of about 13 mm between the slats of the two panels - you do not necessarily have to push the panels completely together.

Step 5: Cutting the Akupanels in width

· At the end of the wall, the panels may have to be adjusted


Akupanel slat woodupp wall panel wholesale

· Cutting the acupanel by cutting the felt with a sharp knife (e.g. cutter knife)

Akupanel slat woodupp wall panel wholesale

· Fix the last acoustic panel to the wall with black screws through the felt

Akupanel slat woodupp wall panel wholesale

Step 6: Length Cutting

· Cut the length of the acupanel with a saw

· Mark the cutting line on the board with a pencil

· After cutting, we recommend to fix the slats back on the felt

· A screw (approx. 15 mm) is screwed through the felt on the back of the panel into the slat

· Then repeat for each slat

Akupanel slat woodupp wall panel wholesale

Congratulations!

Your wall is now fully installed.

The acoustics of the room are now much better and the reverberation is removed, so you can relax and listen to the words of your guests more easily.

If you need help with the installation, please do not hesitate to contact us.

We would be very happy if you send us pictures of your unset project or mark us in the social media.

Have fun with your project!

Akupanel slat woodupp wall panel wholesale

Certificate

Akupanel slat woodupp wall panel wholesaleAkupanel slat woodupp wall panel wholesale
